Germanium Diode

1N34A
Widely used for detecting the rectifying efficiency or for switching on a radio, TV or stereo etc.


GENERAL SPECIFICATIONS
  • Peak Inv. Voltage(PIV): 60 Volts
  • Max. Average Rectified Current: 50mA @ 25 deg C
  • Junction Temperature (TJ): 100 deg C Max.
  • FWD Voltage Drop(VF): 1.0V @ 5.0 mA
  • Reverse Current: IR 15uA @ VR 10 volts

  • $0.30
