UNINTERRUPTIBLE POWER SUPPLY SYSTEMS

We sell UPS systems in our store. All UPS systems come with a power cord. Additional serial cables and software are not provided unless specified and must be purchased separately.

Please email us for a shipping quote for these units. They are moderately heavy (about 15 to 80 pounds) and shipping rates will vary by region.

All UPS systems are guaranteed for 1 year. Batteries are new.

Please call or email and ask for description of what we got.


SUA1500 UPS
Reconditioned with Warranty
$250.00
Pick-up Only

Output

Output Power Capacity 980 Watts / 1440 VA
Max Configurable Power 980 Watts / 1440 VA
Nominal Output Voltage 120V
Output Voltage Distortion Less than 5% at full load
Output Frequency (sync to mains) 47 - 53 Hz for 50 Hz nominal,57 - 63 Hz for 60 Hz nominal
Crest Factor up to 5 : 1
Waveform Type Sine wave
Output Connections (8) NEMA 5-15R

Input

Nominal Input Voltage 120V
Input Frequency 50/60 Hz +/- 3 Hz (auto sensing)
Input Connections NEMA 5-15P
Cord Length 1.83 meters
Input voltage range for main operations 82 - 144V
Input voltage adjustable range for mains operation 75 - 154V

Batteries & Runtime

Battery Type Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time 3 hour(s)
Replacement battery cartridge CURK7, RBC7
RBC™ Quantity 1
Typical Backup Time at Half Load 23.9 minutes (490 Watts)
Typical Backup Time at Full Load  6.7 minutes (980 Watts)
Runtime Chart Smart-UPS

Communications & Management

Interface Port(s) DB-9 RS-232,SmartSlot,USB
Available SmartSlot™ Interface Quantity 1
Control panel LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : and Overload Indicators
Audible Alarm Alarm when on battery : distinctive low battery alarm : configurable delays
Emergency Power Off (EPO) Optional

Surge Protection and Filtering

Surge energy rating 459 Joules
Filtering Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449

Physical

Maximum Height 216.00 mm
Maximum Width 170.00 mm
Maximum depth 439.00 mm
Net Weight 24.09 KG
Shipping Weight 26.36 KG
Shipping Height 381.00 mm
Shipping Width 330.00 mm
Shipping Depth 584.00 mm
Color Black
Units per Pallet 24.00

Environmental

Operating Environment 0 - 40 °C
Operating Relative Humidity 0 - 95%
Operating Elevation 0-3000 meters
Storage Temperature -15 - 45 °C
Storage Relative Humidity 0 - 95%
Storage Elevation 0-15000 meters
Audible noise at 1 meter from surface of unit 45 dBA
Online Thermal Dissipation 135.00 BTU/hr

Conformance

Regulatory Approvals BSMI,CSA,FCC Part 15 Class A,UL 1778








Email us if you have any questions.
